VFH Electric Chain Hoist

Share to

Features

Permanent magnet frequency conversion technology, stable lifting and falling without shaking. Intelligent integrated control appliances can save energy by more than 45%. Electrical control 4v low voltage is safe and reliable, no worry about electric shock
Overload and overheat protection can ensure safe and durable, and high and low speed can be switched at will, which make the machine suitable for different scenarios
Optional-accurate weight display and real-time monitoring, record keeping for query, wireless control + wireless communication
Double safety brake device: When the power is off, the motor decelerates instantly and the mechanical ratchet brake take action at the same time.
The switch line and power line are designed separately, which is easy to install.
Small button switch, easy operation
The main unit is small in size and light in weight and can be moved quickly.
Single 100V-240V power supply can be customized for DC12V, 18V, 24V, 36V, 48V
When the chain reaches the upper or lower limit, the micro switch will be triggered, and the circuit is automatically cut off to prevent machine collision.

Specification Model	Lifting capacity (kg)	Variable frequency motor power(KW)	Lifting Speed（m/min）		Brake	Lifting height（m）	chain (mm)	Power cable length(m)	Control handle cable length (m)	Hook type	N.W(kg)	G.W(kg)	Package size(cm)
Specification Model	Lifting capacity (kg)	Variable frequency motor power(KW)	Low	Hight	Brake	Lifting height（m）	chain (mm)	Power cable length(m)	Control handle cable length (m)	Hook type	N.W(kg)	G.W(kg)	Package size(cm)
NH-300DS	300	1.5	5	9	electric +machanic	3	5×15	4.5	2.5	H105	17	19	50×30×35
NH-500DS	500	1.5	4	6.8							17	19
NH-500DSK	600	2.5	6	10							17	19
NH-1000DS	1000	2.5	4	6.8			7×21			H10	20	23
NH-1000DS/2	1000	1.5	2	3.4			5*15×2			H102	21	24
NH-2000DS	2000	2.5	2	3.4			7*21×2			H202	29	32	50×40×35
