ER Double/Single Speed Electric Chain Hoist (Fixing Type)

Share to

Features

  • Compared with variable pole speed regulation, double speed variable frequency speed regulation can reduce the load swing and achieve a more stable lifting operation.
  • The low speed ratio can be adjusted, so it can achieve smooth start.
  • Improve low speed stop, improve positioning accuracy.
  • The lifting ratio can be adjusted to 6: 1.
  • The moving speed ratio can be adjusted to 6:1.

ER Series Variable Frequency Double Speed Electric Chain Hoist (fixing type)

Product ModelCapacity (ton)Power supplyingControl voltage(V)NO.of load chainLifing motor (variable frequency)
Insulation clas8Rouar (KW)Rotate speed (m/min)Double speed (m/min)
ER0.5-01DF0.53 Phase,
220V/380V,
440V/525V, 50Hz/60Hz		24/36/481F Grade1.5 14401.36-8.2
ER01-01DF111.51.2-7.2
ERO1-02DF121.50.68-4.1
ER1.5-01DF1.513.31.5-9
ER02-01DF213.31.2-7.2
ER02-02DF221.50.6-3.6
ER03-01DF313.31.8-5.6
ER03-02DF323.30.75-4.5
ER05-02DF523.30.55-3.3
ER7.5-03DF7.533.30.38-2.2
ER10-04DF1042×3.30.55-3.3
ER15-06DF1562×3.30.38-2.2
ER20-08DF2082×3.30.28-1.6
ER25-10DF25102×3.30.22-1.3
ER30-12DF30122×3.30.18-1.1

ER Series Single Speed Electric Chain Hoist (fixing type)

ModelCapacity (ton)Power supplyingControl volage(V)NO.of load chainLifting motor (variable frequency)
Insulation classPonar (KW)Rotate speed (m/min)Single speed (m/min)
ER0.5-01SF0.53 Phase,
220V/380V,
440V/525V,
50Hz/60Hz		  24/36/481F Grade1.5       14408.2
ERO1-01SF111.57.2
EROI-02SF121.54.1
ER1.5-01SF1.513.39
ER02-01SF213.37.2
ER02-02SF221.53.6
ER03-01SF313.35.6
ER03-02SF323.34.5
ER05-02SF523.33.3
ER7.5-03SF7.533.32.2
ER10-04SF1042×3.33.3
ER15-06SF1562×3.32.2
ER20-08SF2082×3.31.6
ER25-10SF25102×3.31.3
ER30-12SF30122×3.31.1
